SB29RDC-C0004 - SB ACOUSTICS 1¼" RING TWEETER - RDC
29MMØ RING DOME TEXTILE - 104MMØ FACE PLATE
Notify me when back in stock
29MMØ RING DOME TEXTILE - 104MMØ FACE PLATE Non-resonant diaphragm design for minimum high frequency break-up. Dual balanced compression chamber for improved dynamics. Copper cap for reduced voice coil inductance and minimum phase shift. Saturation controlled motor system for low distortion. Non-reflective rear chamber with optimized damping for improved dynamics. Flow optimized vented pole piece for optimum coupling to rear chamber. CCAW voice coil for low moving mass. Long life silver lead wires. Low resonance frequency. Non-resonant diaphragm design for minimum high frequency break-up Dual balanced compression chamber for improved dynamics Copper cap for reduced voice coil inductance and minimum phase shift Saturation controlled motor system for low distortion Non-reflective rear chamber with optimized damping for improved dynamics Flow optimized vented pole piece for optimum coupling to rear chamber CCAW voice coil for low moving mass Long life silver lead wires Low resonance frequency
(27118)
Order Code | SB29RDC-C0004 |
---|---|
Type | Tweeter |
Size | 1" |
Price Type | each |
Power | 100Wrms |
Coil | 29mmØ |
Width | 104mmØ |
QTY | 1 |
Impedance | 4O (Re 3.0O) |
Depth | 37mm |
Mag. | 0.22kg |
Sens. | 93dB |
Re | 3.0O |
Qms | 2.2 |
Qes | 0.9 |
Qts | 0.64 |
Vas | - |
Sd | 9.6cm² |
Cms | - |
Fs | 600Hz |
Mms | 0.45g |
Zn | 4O |
Le | 0.05mH |
Rms | - |
Diam. | 25mmØ |
Series | Ring Dome |
Page | 10b |
Manufacturer | SB Acoustics |
Prms | 100W |
Materials | Textile |
Impedance (Ohm) | 4 ohm |
Power (RMS) | 51-100 Watt |
Inch | 1 |
SKU | 27118 |
Model # | SB29RDC-C000-4 |
Brand | SB Acoustics |
Shipping Weight | 0.6220kg |
