NE65W-04 - VIFA 2" NE SERIES SPEAKER
NEODYMIUM-IRON-BORON MAGNET
$69.95
In Stock
Notify me when back in stock
NEODYMIUM-IRON-BORON MAGNET The Vifa NE product line has leading-edge transducer technology packaged in a cutting edge, stylistic design. The basket also is designed to act as a highly coupled heat sink to the Neodymium-Iron- Boron magnet (NdFeB) motor, so as to improve power handling capacity. The cone is aluminium, with a butyl rubber surround designed through finite element analysis for linearity of performance. Wide range or mid driver.
(27158)
| Order Code | NE65W-04 |
|---|---|
| Type | Full Range |
| Size | 2" |
| Price Type | each |
| Power | 25Wrms |
| Coil | 25.7mmØ |
| Width | 65mmØ |
| QTY | 1 |
| Impedance | 4O (Re 3.7O) |
| Depth | 34mm |
| Mag. | 140g |
| Sens. | 85.67dB |
| Re | 3.7O |
| Qms | 5.01 |
| Qes | 0.74 |
| Qts | 0.65 |
| Vas | 0.18L |
| Zo | 4 O (Re3.7O) |
| Sd | 14.7cm² |
| Cms | 0.5837mm/N |
| Fs | 166Hz |
| Mms | 1.6g |
| Zn | 4O |
| Le | 0.04mH |
| Manufacturer | Vifa |
| Prms | 25W |
| Impedance (Ohm) | 4 ohm |
| Power (RMS) | 0-50 Watt |
| Inch | 2 |
| SKU | 27158 |
| Model # | NE65W-04 |
| Brand | Vifa |
| Shipping Weight | 0.1360kg |
